wifi认证生产环境下证书生成(wifi认证搭建)

当我们进入测试阶段时,连接苹果电脑和笔记本发现证书需要手动信任,点击进去不是公司信息,是临时信息,如下:

手机端:

wifi认证生产环境下证书生成(wifi认证搭建)

wifi认证生产环境下证书生成(wifi认证搭建)

Pc端:

wifi认证生产环境下证书生成(wifi认证搭建)

根据readme修改为生产证书,操作如下:

# cd /etc/raddb/

# cp -a certs/ /tmp

# ls

wifi认证生产环境下证书生成(wifi认证搭建)

这里的证书是radiusd -X时生成的,当进入生产环境时,删除,修改相关配置,进行make即可。

# rm -f *.pem *.der *.csr *.crt *.key *.p12 serial* index.txt*

# vi ca.cnf

[ ca ]

default_ca = CA_default

[ CA_default ]

dir = ./

certs = $dir

crl_dir = $dir/crl

database = $dir/index.txt

new_certs_dir = $dir

certificate = $dir/ca.pem

serial = $dir/serial

crl = $dir/crl.pem

private_key = $dir/ca.key

RANDFILE = $dir/.rand

name_opt = ca_default

cert_opt = ca_default

default_days = 60

default_crl_days = 30

default_md = sha256

preserve = no

policy = policy_match

crlDistributionPoints = URI:http://www.example.org/example_ca.crl

[ policy_match ]

countryName = match

stateOrProvinceName = match

organizationName = match

organizationalUnitName = optional

commonName = supplied

emailAddress = optional

[ policy_anything ]

countryName = optional

stateOrProvinceName = optional

localityName = optional

organizationName = optional

organizationalUnitName = optional

commonName = supplied

emailAddress = optional

[ req ]

prompt = no

distinguished_name = certificate_authority

default_bits = 2048

input_password = whatever

output_password = whatever

x509_extensions = v3_ca

[certificate_authority]

countryName = FR

stateOrProvinceName = Radius

localityName = Somewhere

organizationName = Example Inc.

emailAddress = admin@example.org

commonName = "Example Certificate Authority"

[v3_ca]

subjectKeyIdentifier = hash

authorityKeyIdentifier = keyid:always,issuer:always

basicConstraints = critical,CA:true

crlDistributionPoints = URI:http://www.example.org/example_ca.crl

修改[ CA_default ]中default_days 和default_crl_days

default_days = 1095

default_crl_days = 730

修改[ req ]部分中input_password和output_password

input_password = 123

output_password = 123

修改[certificate_authority]职工所有信息,按照公司实际修改即可

[server]

countryName = cn

stateOrProvinceName = beijing

localityName = beijing

organizationName = cc

emailAddress = admin@cc.com

commonName = "Cc Wifi Server Certificate"

# vi server.cnf 修改基本同上,不在重复

# vi client.cnf 修改基本同上,不在重复

然后make

# make ca.pem

# make ca.der

# make server.pem

# make server.csr

# make client.pem

生成证书后,重启服务

# systemctl restart radiusd

在访问就是Cc Wifi Server Certificate,详细信息就是上面编辑的信息了。

当然大家可以换成公司自己购买的证书,但是我问了证书厂商,苹果设备还是需要手动信任。
